GT Team Kachinsky 20 BMX / Junior Bike 2021

Inspired by our pro riders, the Team series are ready to handle the heaviest sessions. The frame features a Cr-Mo front triangle for improved strength and is spec'd with a sealed 14mm axle, 9t cassette hub and a double wall rear rim for increased reliability.

features

• GT 4pc Bars
• BK Signature Pivotal
• High-end Metal Flake Finishes

Specification

• FRAME: Cr-Mo Front Tri (T/T, D/T, S/T), DT Gusset, MID BB , Seat Stay U-Brake, Integrated 1-1/8" H/T w/ Removable Rotor Tabs
• FORK: Cr-Mo 2pc. Threaded Steerer & Tapered Legs, 31mm OffSet, 3/8" Axle Dropouts
• CHAIN: KMC Z410
• CRANK: GT Power Series Cr-Mo 3pc., 170mm Arms, 19mm x 8T Cr-Mo Spindle, GT 25T Steel Chainwheel
• BOTTOM BRACKET: MID Sealed Bearing
• PEDALS: GT Low Profile FS Platform Design
• COG SET: 9T 1pc. Driver
• RIMS: Alloy Single Wall (F), Double Wall (R) 36h
• TIRES: GT Pool 20 x 2.3"
• FRONT HUB: Alloy Body, Sealed Bearings 3/8" Axle, 36h, 15mm Nut
• REAR HUB: Alloy Body, 5pcs Sealed Bearings, Cr-Mo 14mm x 165mm Axle, 9T Cassette, 36h, 17mm Nut
• SPOKES: Stainless Steel, 14g
• BRAKES: Aluminum U-Brake w/ Soft Compound Pad
• FRONT BRAKE: Aluminum U-Brake w/ Soft Compound Pad
• REAR BRAKE: Aluminum U-Brake w/ Soft Compound Pad
• BRAKE LEVERS: Alloy U-type
• HANDLEBAR: GT Freestyle 4pc., Steel, 9.125"H x 29"W, 5° Up, 9° Back
• STEM: GT Top Load, 1-1/8", Cold Forged Cap, 32mm Rise, 50mm
• GRIPS: GT Super Soft 155mm Single Compound w/o Flange w/ GT Removable Plug
• HEADSET: 1 1/8" Integrated Design, 45X45 Degree Sealed Bearings
• SADDLE: GT BK Signature Pivotal
• SEAT POST: Alloy Pivotal 25.4 x 200mm

Geometry
